The WCCTV 4G Compact DVR is a four camera wireless CCTV device. It can be used with any industry standard cameras to create multiple bespoke covert or overt wireless surveillance solutions.

The unit contains a removable hard drive (up to 2TB) for digital evidential quality recording. Users can remotely access live and recorded video and audio via 4G technology. Automatic fall-back to 3G, HSDPA, UMTS and GPRS provides optimal flexibility.

The WCCTV 4G Compact features multiple connections for video, alarm, telemetry and power. Each connection allows the end user to remotely control any camera with pan, tilt and zoom capabilities, using WCCTV’s free unlicensed software from any laptop, desktop PC or control room.

Features and Benefits

  • Ideal for integration

  • Portable surveillance solution

  • Four channel output

  • Compatible with any industry standard camera

  • Digital recording

  • Up to 2TB local recording

  • Multiple transmission options, including 4G, 3G HSUPA, Wi-Fi and broadband

  • Rapid installation

  • Remote access to live and recorded footage

  • Remote control of cameras and other linked devices

  • Unlicensed software, unlimited users at no additional cost

  • Full control room integration

  • Smartphone access

  • Ideal for vehicle-fitted CCTV

Applications

  • Bespoke wireless CCTV

  • Cable and metal theft

  • Covert applications

  • Vehicle solutions

  • Crime and disorder

  • Remote evidence gathering

  • Bearer device on other systems



WCCTV - 4G Compact - Vehicle Fitted Solution

Transmission methods

WCCTV provides the most competitive data packages, with all products specifically designed for the secure transmission of video over mobile networks.

  • 4G (with fall back to 3G, HSUPA, HSDPA and GPRS)

  • IP/Broadband

  • LAN-only

  • Wi-Fi (Long range up to 2km, short-range 100m)

Purchase Information

For purchase information please complete a contact form.

Alternatively you can contact WCCTV on 0800 470 4630 or sales@wcctv.com

General
Dimensions (HxWxD) 270mm x 200mm x 65mm
Operating Temperature Range -50 to 50°C
Power 100-240 Volt input (mains powered) or 12 Volt DC (battery powered)
Power Consumption 1A (minimal)
Weight 900G
Software Upgrade Internet / 4G / 3G / Back to Back PC



Video
Video Inputs 4
Operation Simultaneous live, record, playback, remote access
Maximum FPS 25
Recording Proprietary narrowband algorithm
MutiMode (recording algorithms)     Dynamically changes record rates and compression settings for the camera
Snapshot Video Clip Yes
Video Motion Search Yes
Archive Protection Yes - protect against overwriting
Wireless Communication Supported via suitable interface - GSM, GPRS, UMTS, HSDPA, HSCSD, 3G, 4G



Storage
Maximum Internal Capacity     1TB
Hard Disk Drive Types Removable SATA Drive
Export 4G / HSUPA / Network / Optional removable SATA Drive



Alarms
Alarms 2 camera control, 1 alarm, 1 arming / disarming and 2 auxiliary inputs
Alarm Function Support Alarm log, event search, pre-event recording
Alarm Reporting Yes - to a remote site via email
Display Alarm on PC Monitor       Yes or network / HSUPA / 4G
Relays 2 relays - system error and/or remote control purposes
Video Motion Detection Yes



Networking
Remote PC Client                Client Software Free Download
Remote Web Browser Client Viewing
Password Protected Yes
Smartphone Compatible Yes
Tablet Compatible Yes
