WCCTV 4G IR Speed Dome with ANPR

View all category:

Dome

Make an enquiry
Product Information
Product Specification

WCCTV’s combined ANPR and Redeployable CCTV system utilises the additional output channels of the WCCTV 4G IR Speed Dome to integrate a specialised Automatic Number Plate Recognition camera.

This unique all-in-one rapid-deployment surveillance system combines all of the benefits of redeployable CCTV with automatic number plate recognition technology for advanced surveillance applications.

The wireless transmission (4G/3G/Wi-Fi), local recording (up to 4TB) and 360° PTZ field of vision of the WCCTV 4G IR Speed Dome range provides a complete situational overview.

The ANPR camera captures and stores images of number plates, stores them and converts them into a text database that shows the number plate, date and time stamp and the direction of travel.

This database can be accessed and downloaded remotely over 4G connectivity, providing full statistical analysis and/or allowing the searching of a specific number plate or activity during a specific period of time.

The WCCTV 4G IR Speed Dome + ANPR system is ideal for strategic data collection along roadways, bridges, tunnels, key road junctions, entrances to buildings or other critical infrastructure. It is also an ideal crime-fighting tool against fly-tipping, parking offences, traffic violations and more.

The ANPR camera can read license plates day and night, under any kind of weather conditions on vehicles travelling up to 130mph.

The unit also features additional channel outputs, enabling the integration of other cameras, and the addition of a WCCTV Smart Switch.

Features and Benefits

  • High accuracy automatic number plate recognition

  • Snapshot images converted and stored to database

  • Remote access to evidential, removable, digital recording and database

  • Full day and night operation

  • All weather conditions operation

  • Complete situation overview

  • Portable & rapidly deployable

  • Lightweight integrated unit

  • Control room integration

  • High Definition images delivered via both cameras

  • Built-in self-testing diagnostics

  • Remote control with full 360° pan, tilt & zoom functionality

  • Up to 4TB internal storage

  • IP65 rated

  • Remote power cycle option

  • Ongoing health-check option

Applications

 WCCTV Islington Council

1

Transmission methods

WCCTV provides the most competitive data packages, with all products specifically designed for the secure transmission of video over mobile networks.

  • 4G (with fall back to 3G, HSUPA, HSDPA and GPRS)

  • IP/Broadband

  • LAN-only

  • Wi-Fi (Long range up to 2km, short-range 100m)

Purchase Information

For purchase information please complete a contact form.

Alternatively you can contact WCCTV on 0800 470 4630 or sales@wcctv.com

General
Dimensions (HxWxD) 350mm x 150mm x 225mm \ ANPR - 348mm × 114mm ×111mm
Operating Temperature Range WCCTV Dome -30 to 50°C \ ANPR - -30 to 60°C
Power 110-240 Volt input (mains powered) 12 Volt DC (battery powered)
Power Consumption WCCTV Dome - 24W @ 240 V \ ANPR - Max. 15W
Weight WCCTV Dome - 6KG \ ANPR 1.9 KG
Software Upgrade Internet / 4G / 3G / Back to Back PC



Video
Video Inputs 4
Operation Simultaneous live, record, playback, remote access
Optical/Digital Zoom 25x / 16x
Resolution of Camera 1080p
Maximum FPS 25
Recording Proprietary narrowband algorithm
MutiMode (recording algorithms)     Dynamically changes record rates and compression settings for the camera
Snapshot Video Clip Yes
Video Motion Search Yes
Archive Protection Yes - protect against overwriting and adjustable retention period
Wireless Communication Supported via suitable interface - GSM, GPRS, UMTS, HSDPA, HSCSD, 3G, 4G, Wi-Fi
IR Range 50M
ANPR Recoginition Number plate search and functionality, black and white list capability



Storage
Maximum Internal Capacity     Up to 4TB
Hard Disk Drive Types Removable SATA hard disk drive
Export HSUPA/ network / optional removable SATA hard disk drive
ANPR Storage 128GB



Alarms
Alarms 2 camera control, 1 alarm, 1 arming / disarming and 2 auxiliary inputs
Alarm Function Support Alarm log, event search, pre-event recording
Alarm Reporting Yes - to a remote site via email
Display Alarm on PC Monitor       Yes or network / HSUPA / 4G
Relays 2 relays - system error and/or remote control purposes
Video Motion Detection Yes



Networking
Remote PC Client                Client Software Free Download
Remote Web Browser Client Viewing
Password Protected Yes
Smartphone Compatible Yes
Tablet Compatible Yes
